A novel fast version of particle swarm optimization method applied to the problem of optimal capacitor placement in radial distribution systems

Full Text(PDF, 3000) PP.


Author(s)
M.Pourmahmood Aghababa, A.M.Shotorbani, R.Alizadeh, R.M.Shotorbani

KEYWORDS
convergence speed, fast PSO, capacitor placement, particle swarm optimization, radial distribution system


ABSTRACT
Particle swarm optimization (PSO) is a popular and robust strategy for optimization problems. One main difficulty in applying PSO to realworld applications is that PSO usually needs a large number of fitness evaluations before a satisfying result can be obtained. This paper presents a modified version of PSO method that can converge to the optima with less function evaluation than standard PSO. The main idea is inserting two additional terms to the particles velocity expression. In any iteration, the value of the objective function is a criterion presenting the relative improvement of current movement with respect to the previous one. Therefore, the difference between the values of the objective function in subsequent iterations can be added to velocity of particles, interpreted as the particle acceleration. By this modification, the convergence becomes fast due to new adaptive step sizes. This new version of PSO is called Fast PSO (FPSO). To evaluate the efficiency of FPSO, a set of benchmark functions are employed, and an optimal capacitor selection and placement problem in radial distribution systems is evaluated in order to minimize cost of the equipment, installation and power loss under the additional constraints. The results show the efficiency and superiority of FPSO method rather than standard PSO and genetic algorithm.


References

[1] M. Lovberg and T.Krink, “Extending Particle Swarm Optimizers with SelfOrganized Criticality,” In Proceeding of Forth Congress on Evolutionary Computation, vol. 2, pp.1588 1593, 2002.
[2] J. Kennedy and R. Eberhart, “Particle Swarm Optimization,” In Proceedings of IEEE International Conference on Neural Networks, Perth, Australia, vol.4, pp.19421948, 1995.
[3] J.H. Holland, Adaptation in Natural and Artificial Systems, University of Michigan Press, Ann Arbor, MI, Internal Report, 1975.
[4] H. N. Ng, M. M. A. Salama, A. Y. Chikhani, “Capacitor Allocation by Approximate Reasoning: Fuzzy Capacitor Placement,” IEEE Transactions on Power Delivery, vol. 15, no. 1, pp. 393  398, Jan 2000.
[5] J. J. Grainger and S. H. Lee, “Capacity release by shunt capacitor placement on distribution feeders: A new voltagedependent model,” IEEE Trans. Power Apparatus and Systems, vol. PAS101, no. 15, pp. 1236–1244, May 1982.
[6] J. L. Bala, P. A. Kuntz, and M. J. Pebles, “Optimal capacitor allocation using a distributionrecorder,” IEEE Trans. Power Delivery, vol. 12, no. 1, pp. 464–469, Jan 1997.
[7] M. Kaplan, “Optimization of number, location, size, control type, and control setting of shunt capacitors on radial distribution feeders,” IEEE Trans. Power Apparatus and Systems, vol. PAS103, no. 9, pp. 2659–2663, Sept 1984.
[8] H. D. Chiang, J. C. Wang, O. Cockings, and H. D. Shin, “Optimal capacitor placement in distribution systems—Part I: A new formulation and the overall problem,” IEEE Trans. Power Delivery, vol. 5, no. 2, pp. 634– 642, Apr 1990.
[9] S. Sundhararajan and A. Pahwa, “Optimal selection of capacitors for radial distribution systems using a genetic algorithm,” IEEE Trans. Power Systems, vol. 9, no. 3, pp. 1499–1505, Aug 1994.
[10] Y. C. Huang, H. T. Yang, and C. L. Huang, “Solving the capacitor placement problem in a radial distribution system using tabu search approach,” IEEE Trans. Power Syst., vol. 11, no. 4, pp. 1868–1873, Nov 1996.
[11] M. Delfanti, G. P. Granelli, P. Marannino and M. Montagna, “Optimal capacitor placement using deterministic and genetic algorithms,” Power Industry Computer Applications, 1999. PICA '99. Proc. of the 21st IEEE International Conference, pp. 331336, 1999
[12] Y. Shi and R. Eberhart, “A modified particle swarm optimizer,” Proceedings of the IEEE international conference on evolutionary computation, Piscataway, NJ: IEEE Press, pp. 69–73, 1998.
[13] J. Kennedy and R. Eberhart, “A Discrete Binary Version of the Particle Swarm Algorithm,” In Proceedings of the Conference on Systems, Man, and Cybernetics, pp. 41044109, 1997.
[14] Y. Baghzouz and S. Ertem, “Shunt capacitor sizing for radial distribution feeders with distorted substation voltages,” IEEE Trans Power Delivery, vol. 5, no. 2, pp. 650–656, 1990.
[15] J. J. Grainer and W. D. Stevenson, Power system analysis, New York: McGrawHill, ISBN No. 0071133380, 1991.
[16] Y. Baghzouz, “Effects of nonlinear loads on optimal capacitor placement in radial feeders,” IEEE Trans Power Delivery, vol. 6, no. 1, pp. 245– 251, 1991.
[17] S. Sundhararajan and A. Pahwa, “Optimal selection of capacitors for radial distribution systems using a genetic algorithm,” IEEE Trans Power Systems, vol. 93, pp. 1499–1507, Aug 1994.
[18] T. S. Chung and H. C. Leung, “Agenetic algorithm approach in optimal capacitor selection with harmonic distortion consideration,” Elsevier, Electrical Power and Energy systems, vol. 21, pp. 561569, 1999.
[19] R. Chelouah and P. Siarry, “Genetic and NelderMead Algorithms hybridized for a More Accurate Global Optimization of Continuous Multiminima Functions,” European Journal of Operational Research, vol. 148, pp. 335348, 2003.
